Different length will be different price, kindly contact us for detail price and leadtime.
SOGOO TECHNOLOGY CO., LTD
Mob/Wechat: +86-150-1946-5365
Whatsapp Business: +852 66425118
E-mail: sales@sogootech.com
Website: www.sogootech.com
www.telecomscable.com
Fiber Optic Patch Cords are comprised of a polymer outer body and inner assembly fitted with a precision alignment mechanism. Refer to the diagram above for dimensional information. These adaptors are precision made and manufactured to demanding specifications. The combination of a ceramic/phosphor bronze alignment sleeves and a precision moulded polymer housing provides consistent long-term mechanical and optical performance.
Typical Usages
Fiber Optic Data Transmission System
Military Tactcial Field,
Shipboard,aerospace,
Automotive Commercial
Typical Advantage
Low Insertion Loss, High Reliability
Easy to Install with Removable Parts
Water/Dust Proof,Anti Corrosion
High Tensile Load Capability
Excellent Termination Strength
Performances Specifications
| Parameter | Unit | FC,SC,LC | ST,MU,MTRJ, | |||
| SM | MM | SM | MM | |||
| UPC | APC | UPC | UPC | UPC | ||
| Insertion Loss | dB | ≤0.2 | ≤0.2 | |||
| Return Loss | dB | ≥55 | ≥65 | ≥35 | ≥55 | ≥35 |
| Repeatability | dB | IL≤0.2 RL≥5 | IL≤0.1 | IL≤0.1 | IL≤0.1 | |
| Durability | dB | IL≤0.2 RL≥5 | IL≤0.1 | IL≤0.1 | IL≤0.1 | |
| Exchangeability | dB | IL≤0.2 RL≥5 | IL≤0.1 | IL≤0.1 | IL≤0.1 | |
| Compressive Strength | N | F>300 | ||||
| Operation life Span | Times | n>1000 | ||||
| Operation Temperature | ℃ | -40~75 | ||||
| Storage Temperature | ℃ | -45~85 | ||||
| Cable Diameter | cm | 0.9,2.0,3.0 or specified | ||||
