Outdoor waterproof Tactical fiber 12 24 cores SM OM3 OM4 Cable ODVA MPO MTP Connector
1.MPO(multi-fiber Push On) connector is one of the MT series connectors.
2.MPO connector and fiber optic cable processing can produce various forms of MPO jumper.
3.MPO jumpers are widely used in high-density integrated optical fiber line environments.
4.The total length of MPO jumper or branch length and other requirements are at the customer's option.
APPLICATION
Data communication network
Optical System Access network
Storage area networking fiber channel
High density architectures
FEATURES
Available for standard or low loss MPO/MTP® interface
Bayonet locking design with IP68 sealing
Highly customizable configurations
Designed with protective housing, which fulfills IP67 environmental sealing
| | |
Connector | Mode | Endface | IL(max) (dB) | RL(min) (dB) | IL(max) (dB) | RL(min) (dB) |
MPO/MTP | SM | 12F/APC | ≤0.70 | ≥60 | ≤0.35 | ≥60 |
24F/APC | ≤0.75 | ≥60 | ≤0.35 | ≥60 |
48F/APC | ≤0.75 | ≥60 | | |
MM | 12F/PC | ≤0.50 | ≥20 | ≤0.35 | ≥20 |
24F/PC | ≤0.50 | ≥20 | ≤0.35 | ≥20 |
48F/PC | ≤0.50 | ≥20 | | |
LC/SC/FC/ST | SM | APC | ≤0.30 | ≥60 | ≤0.10 | ≥60 |
UPC | ≤0.20 | ≥50 | ≤0.10 | ≥50 |
MM | PC | ≤0.20 | ≥30 | ≤0.10 | ≥30 |
Note:
1.Test wavelength:SM@1310/1550nm,MM@850/1300nm;
2.Standard conformance: GR-326,GR-1435.
|
Item | Criteria | Conformance |
△IL After 50 Matings | MPO/MTP | ≤0.3dB | GR-1435 |
△IL After 500 Matings | LC/SC/FC/ST | ≤0.2dB | IEC 61300-2-2 |
Min Bend Radius (Dynamic) | 20*OD (Cable Diameter) |
Min Bend Radius (Static ) | 15*OD (Cable Diameter) |
|
Item | Criteria | Conformance |
Operation Temperature | -40~60°C | IEC 61753-1 |
Storage Temperature | -45~85°C |
